Allen-Bradley 2711R-T7T PanelView 800 7-Inch HMI Terminal · 800 × 480 Touchscreen
Allen-Bradley 2711R-T7T HMI terminal
PanelView 800 7-inch touchscreen
800 × 480 HMI terminal with warranty
Place of Origin:
USA
Brand Name:
Allen Bradley
Allen-Bradley 2711R-T7T HMI terminal
,PanelView 800 7-inch touchscreen
,800 × 480 HMI terminal with warranty
2711R-T7T PanelView 800 7-Inch HMI Terminal
A 7-inch touch operator terminal with an 800 × 480 color display, Ethernet and serial communication interfaces, and 24V DC power input.
2711R-T7T specifications
View additional specifications +
| Display colors | 65K colors |
| Real-time clock | Integrated, battery-backed |
| Battery life | Minimum 5 years at 25 °C |
| Ethernet | 1 × 10/100 Mbps |
| Serial communication | RS-232 and isolated RS-422/485 interfaces |
| USB | USB 2.0 host |
| MicroSD | MicroSD card slot |
| Operating system | WINCE 6.0 |
| Engineering software | Connected Components Workbench software, release 8.0 and later |
| Dimensions H × W × D | Approx. 144 × 197 × 54 mm |
| Panel cutout | Approx. 125 × 179 mm |
| Approximate weight | 0.651 kg |
| Operating temperature | 0…50 °C |
| Nonoperating temperature | -25…70 °C |
| Relative humidity | 5…95%, noncondensing |
| Front protection | IP65; NEMA 4X, 12, 13 |
Built around compact machine control
The PanelView 800 platform is intended for operator interaction with Micro800 and MicroLogix environments and is used across applications such as material handling, air handling, food processing, adhesive labeling and stretch wrapping.
Exact catalog-number searches are relevant when an installed operator terminal needs replacement or maintenance identification.
Loss of normal display, touch response or communication can lead maintenance teams back to the installed terminal model.
A failed operator interface can interrupt normal machine monitoring and operator interaction during production or maintenance.
Connected Components workflow
Configuration is centered on Connected Components Workbench, with Ethernet and serial communication options for supported controller and device networks.
Connected Components Workbench is the designated development and configuration environment for the PanelView 800 family.
The platform supports Ethernet-based and serial communication options documented for PanelView 800 applications.
VNC support is available on supported PanelView 800 firmware revisions.
Panel mounting and field connection
The terminal is panel mounted using mounting levers. Installation documentation covers panel preparation, grounding and device connections.
Follow the applicable Rockwell Automation installation instructions for enclosure preparation, wiring and grounding.
Practical maintenance checkpoints
For a nonresponsive terminal, maintenance checks should begin with the installation, power and communication conditions before identifying whether the terminal itself requires replacement.
Check the specified DC supply and field wiring.
Check the applicable Ethernet or serial connection.
Check the installed firmware revision when software or communication behavior is involved.
Engineering reference
Rockwell Automation lists Publication 2711R-TD001 for technical specifications, Publication 2711R-IN001 for installation, and Publication 2711R-UM001 for user and configuration information.
Delivery and after-sales
AMIKON provides testing or inspection where applicable, protective export packaging, one-year warranty under quotation terms, and after-sales handling for DOA cases with arrival photos and test details.
