ABB IMDSM05 Digital I/O Slave Module, 16-Channel 24 VDC
ABB PLC digital I/O module
16-channel 24VDC slave module
ABB IMDSM05 I/O module
Place of Origin:
SWEDEN
Brand Name:
ABB
Model Number:
IMDSM05
ABB PLC digital I/O module
,16-channel 24VDC slave module
,ABB IMDSM05 I/O module
ABB IMDSM05
ABB IMDSM05 is a Digital I/O Slave Module with 16 digital I/O channels. The channels are arranged in two groups of eight, with each group configurable as an input or output group.
Overview
IMDSM05 is part of the Symphony Harmony I/O architecture. The module provides 16 digital I/O channels for 24 VDC signals.
The 16 channels are divided into two groups of eight. Each group can be configured as an input group or an output group.
Technical Specifications
Signal Path / Architecture
Applications
Digital I/O in Symphony Harmony Systems
IMDSM05 is used where digital input and output signals are required within the Symphony Harmony I/O architecture. Its two groups of eight channels can be configured according to the required digital I/O arrangement.
During maintenance or spare-part sourcing, the module may be identified by its IMDSM05 part number and its installed digital I/O configuration. Correct identification is important when restoring an existing Harmony I/O arrangement.
ABB's Harmony documentation identifies different replacement arrangements depending on the configuration of IMDSM05. ABB states that there is no direct replacement when IMDSM05 is used for both inputs and outputs, or when it is used with a Digital Logic Station (DLS).
