GE IS220PAICH1B is a Mark VIe Control Analog I/O Module designed for analog signal interfacing within GE Mark VIe control systems. The module supports voltage and current analog inputs, analog output, and 24 VDC transmitter power.
It is suitable for Mark VIe system maintenance, module replacement, and spare-part requirements where the existing system configuration matches the specified I/O and terminal board arrangement.
| Model | IS220PAICH1B |
| Series | GE Mark VIe |
| Module Type | Control Analog I/O Module |
| Input Power | 24-28 VDC |
| Maximum Current | 0.49 A |
| Analog Inputs 1-8 | -10 to +10 VDC / 0-20 mA DC |
| Analog Inputs 9-10 | -5 to +5 VDC / -1 to 20 mA DC |
| Analog Output | 0-16.3 VDC / 0-20 mA DC |
| Transmitter Power | 24 VDC, 21 mA DC |
| Operating Ambient Temperature | -30°C to +65°C |
Source: GE / GE Vernova official Mark VIe ATEX and IECEx certification documentation.
Officially documented compatible terminal boards:
- ISx0ySTAIH1A
- ISx0ySTAIH2A
- ISx0yTBAIH1C
GE documentation also identifies IS400BPAIH1A and IS400BPAIH2A in the applicable Mark VIe configuration.
Official replacement: No specific GE replacement part number has been confirmed in the official documents reviewed.
IS220PAICH1B is used in GE Mark VIe control systems for analog field signal interfacing. Typical maintenance searches for this module may arise when an existing PAIC module has issues with:
- Analog input signal acquisition
- Voltage or current signal channels
- Analog output
- Transmitter power
- I/O module operation within the Mark VIe system
A failed analog I/O module can affect the associated field signal monitoring or control function. The actual impact on plant operation depends on the process channel and control strategy connected to the module.
AMIKON - Industrial Automation Spare Parts
AMIKON specializes in DCS, PLC, and industrial automation spare parts, with access to 30,000+ parts and global sourcing support for hard-to-find, obsolete, and discontinued components.
Each product is inspected and tested before shipment. We also provide warranty and after-sales support for maintenance, repair, and replacement requirements.
Need a quote? Contact us for availability and pricing.
Contact: Miya Zheng
Email: sales@amikon.cn
WhatsApp: +86 180 2077 6792
Q1. What hazardous-area certification applies to IS220PAICH1B?
The applicable certification marking is Ex ic ec [ic] IIC T4 Gc.
Q2. What are the intrinsically safe parameters of IS220PAICH1B?
The official documentation specifies Uo 28.6 VDC, Io 22.4 mA, Po 0.641 W, Co 0.255 μF, and Lo 100 mH for the applicable field-wiring configuration.
Q3. Which terminal boards are listed with IS220PAICH1B for intrinsically safe field wiring?
The documented combinations include IS200STAIH1A, IS200STAIH2A, IS200TBAIH1C, IS400BPAIH1A, IS400STAIH1A, IS400STAIH2A, and IS400TBAIH1C.
Q4. What system is IS220PAICH1B used in?
It is identified by GE as a Mark VIe Control Analog I/O Module.
Q5. What are the delivery and warranty terms for IS220PAICH1B?
IS220PAICH1B is inspected and securely packaged before shipment. Warranty coverage, returns, and DOA handling are subject to Amikon's applicable sales and warranty terms.
Q6. What information is required for an IS220PAICH1B RFQ?
Please provide the Part Number, Quantity, Destination, Required Date, and Machine/System Model for quotation and availability confirmation.
These models are listed as available inventory only and are not official or compatible replacement models for IS220PAICH1B.
