Bently Nevada 3500/42M 140734-02 Proximity/Seismic Monitor Module with 4 Configurable Channels
Bently Nevada 3500/42M 140734-02 Proximity/Seismic Monitor Module with 4 Configurable Channels
4 Configurable Channels Proximity/Seismic Monitor Module
Real-time Filtering Bently Nevada 3500/42M
Continuous Comparator Logic Machinery Protection Module
Place of Origin:
USA
Brand Name:
Bently Nevada
Model Number:
3500/42M 140734-02
Contact Us
Request A Quote
Product Details
Product Parameters:
Proximity/Seismic Monitor Module
Manufacturer:
Bently Nevada
Weight:
0.85 Kg
Output Impedance:
550 Ω
Transducer Power Supply:
-24 Vdc
Voltage Compliance:
0 To +12 Vdc Range Acrossload
Gap Filter:
-3 DB At 0.09 Hz
Smax:
Within ±5% Maximum
Highlight:
4 Configurable Channels Proximity/Seismic Monitor Module
,Real-time Filtering Bently Nevada 3500/42M
,Continuous Comparator Logic Machinery Protection Module
Payment & Shipping Terms
Minimum Order Quantity
1
Price
66USD
Packaging Details
Brand new and original
Delivery Time
2-3 work days
Payment Terms
T/T
Supply Ability
in stock
RELATED PRODUCTS
CONTACT US
Contact Now
Product Description
Core Functionality
Signal Acquisition: Interfaces with mixed-mode transducers via four configurable channels supporting proximity probes (non-contact eddy current displacement/gap) and seismic transducers (accelerometers and velomitors for casing vibration).
Conditioning Core: Performs real-time filtering, integration, and rectification of raw analog signals, converting voltages into engineering units for both static and dynamic measurements.
Protection Logic: Executes continuous comparator logic comparing conditioned signals against user-defined setpoints, instantly driving internal alarm flags when thresholds are exceeded.
Data Annunciation: Provides dual data streams - real-time status for operations and buffered high-resolution data for maintenance and analysis.
Technical Specifications
INPUT_TOPOLOGY:
4 x Configurable Channels. Supports mixed-mode transducer inputs without external multiplexing.
TRANSDUCER_MAP:
Proximity: Non-contact eddy current (Displacement/Gap).
Seismic: Accelerometers and Velomitors (Casing Vibration).
SIGNAL_PATH_COND:
Executes real-time filtering, integration, and rectification. Transmutes raw analog voltages into calibrated Engineering Units prior to logic evaluation.
MEASUREMENT_VECTORS:
Static Data: Axial Position, Eccentricity.
Dynamic Data: Radial Vibration, Velocity, Acceleration.
PROTECTION_ALGORITHM:
Continuous Comparator Logic. Compares Conditioned Signal vs. User-Defined Setpoints in real-time.
ACTUATION_RESPONSE:
Instantly drives internal Alert/Danger flags. Triggers associated Relay Modules to initiate machine trip/shutdown sequences.
DATA_STREAM_A [OPS]:
Real-time Status. Delivers immediate alarm states and current values to control room operators for process monitoring.
DATA_STREAM_B [ENG]:
Buffered High-Res Data. Captures static/dynamic waveforms for reliability engineers to facilitate root-cause analysis and predictive maintenance.
Available Inventory Categories
The Big Three: Deep stock of ABB (DSQC robots & Bailey DCS), Honeywell (51/MU/MC/TC/CC boards), and Allen Bradley (1756/1747/1746).
Turbines & Vibration: Bently Nevada 3500/3300 racks and cables, GE DS200 cards, and standard IC693/697 PLCs.
Safety Systems: Critical stock available for Triconex (3008/3511/3721) and Westinghouse (1C/5X).
Legacy Systems: Hard-to-find parts from Siemens (6DD/6DP/6ES5), Schneider (140 Series), and Foxboro (FBM/FCP).
