GE IS220PSCAH1B Serial Communications Module Mark VIe Serial I/O Pack
GE IS220PSCAH1B
IS220PSCAH1B Serial Communications Module
GE Mark VIe I/O Pack
Place of Origin:
USA
Brand Name:
General Electric
GE IS220PSCAH1B
,IS220PSCAH1B Serial Communications Module
,GE Mark VIe I/O Pack
GE IS220PSCAH1B Serial Communications Module
AMIKON supplies industrial automation spare parts for maintenance and repair requirements. Contact us to check sourcing options for the GE IS220PSCAH1B and confirm the appropriate hardware for your installation.
Communications Architecture
The IS220PSCAH1B connects the Mark VIe I/O network with serial communication equipment through an associated terminal board. Its communication channels can be configured for the serial interface required by the connected equipment.
Technical Specifications
| Product Type | PSCA Serial Communications I/O Pack |
| Control Platform | Mark VIe |
| Serial Transceiver Channels | 6 independently configurable channels |
| Serial Interface Standards | RS-232, RS-422 and RS-485 half-duplex |
| Ethernet Ports | 2 RJ45 Ethernet connections |
| Power Connector | 3-pin power input |
| Terminal-Board Connector | DC-62 pin connector |
| Local Indication | Status indicator LEDs |
| Configuration Software | ToolboxST |
| Associated Terminal Boards | IS200SSCAH1A and IS200SSCAH2A |
| Power Supply Voltage | Minimum 22.5 V DC; nominal 24.0 / 28.0 V DC; maximum 28.6 V DC |
| Maximum Input Current | 0.36 A |
Application & Failure Scenarios
Typical Maintenance Requirements
- Restoring communication with connected serial devices.
- Investigating intermittent serial data or communication alarms.
- Checking module status when a communication fault occurs.
- Replacing a suspected faulty I/O pack during maintenance.
Operational Impact
When a required serial communication path is interrupted, the control system may lose data from connected devices. The effect on monitoring or control depends on the role of that device within the plant system.
Installation & Troubleshooting
Installation Sequence
- Secure the terminal board. Install the selected terminal board in its intended mounting position before fitting the I/O pack.
- Connect the pack. Seat the IS220PSCAH1B directly onto the terminal-board connector. Align the pack correctly before securing it.
- Fit the mounting bracket. Use the threaded inserts beside the Ethernet ports and the bracket intended for the terminal-board type. Position the bracket to avoid applying a right-angle force to the DC-62 connector.
Communication Fault Checks
- Check the power connection and module LED status.
- Inspect the Ethernet cables and confirm the network connection.
- Check that the pack is correctly seated and secured to the terminal board.
- Confirm that the selected serial mode matches the connected device and its wiring.
Delivery, Warranty & Returns
Supply & Packaging
Availability and dispatch timing are confirmed during quotation. Items receive order and visible-condition checks before shipment and are packed for transport protection.
Warranty & DOA Support
Warranty duration and coverage follow the sales confirmation. Report suspected DOA or transit damage promptly with order details and photos. Returns require prior authorization and are subject to the agreed terms.
Frequently Asked Questions
The communications board provides six independently configurable serial transceiver channels, supporting RS-232, RS-422 and RS-485 half-duplex modes.
The IS220PSCAH1B is associated with IS200SSCAH1A and IS200SSCAH2A terminal boards in the GE Mark VIe hazardous-location equipment documentation. Confirm the required combination for your system before ordering.
Check power and LED status, Ethernet connections, pack seating, terminal-board connections, serial wiring, communication settings and system diagnostics.
Contact AMIKON with the complete catalog number and system details to ask about available documentation and sourcing options.
