Honeywell CC-PFB802 51454953-176 FOUNDATION Fieldbus Interface Module
Honeywell CC-PFB802
FOUNDATION Fieldbus Interface Module
8 H1 Networks
Brand Name:
Honeywell
Honeywell CC-PFB802
,FOUNDATION Fieldbus Interface Module
,8 H1 Networks
AMIKON Industrial Supply / Industrial Parts Sourcing, Kept Practical
Honeywell CC-PFB802 51454953-176 FOUNDATION Fieldbus Interface Module
Designed for FOUNDATION Fieldbus H1 integration in Honeywell Experion PKS Series C process control environments, this FIM8 interface supports fieldbus connectivity for industrial process instrumentation. Check the installed hardware arrangement and system revision before ordering a replacement.
Technical Specifications
| Product Family | Series C |
| Module Type | FOUNDATION Fieldbus Interface Module (FIM8) |
| Physical Interface | H1 FOUNDATION Fieldbus |
| H1 Network Capacity | 8 H1 networks per FIM |
| H1 Network Rate | 31.25 kbps per H1 network |
| Module Construction | Series C module, conformally coated |
| Module Indicators | 24 V power, module status and FTE status LEDs; front display panel provides module and link state information |
| IOTA Indicators | 8 H1 link status LEDs, one per link |
| Supported Configurations | Non-redundant or redundant, side-by-side |
| Power Dissipation | 9.5 W |
| Module Current | 0.380 A at 25 V DC |
| H1 Link Connection | Through connectors on the IOTA |
