Bently Nevada 135813-01 3500/93 Display Interface Input/Output (I/O) Module
Product Overview
| Parameter | Specification |
|---|---|
| Module Type | Full-height, rear I/O module |
| Slot Placement | Installs into any standard rear slot of the 3500 chassis |
| Hardware Protocol | RS422 serial interface |
| Connection Link | Dedicated terminal connector linking the main front panel display to the rear rack |
| System Capacity | Max 2 System Displays can be connected to each 3500 monitoring rack |
| Major Components | Part of the 3500/93 system (consisting of Display Unit, Display Interface Module, and this I/O module) |
| Combined Max Power | 15.5 watts maximum (Display Unit and Display Interface Module combined) |
| Configuration Method | Configured using official 3500 Rack Configuration Software |
| Operating Temperature | 0°C to +65°C (+32°F to +150°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Operating Humidity | Max 95%, non-condensing |
Contact Us for Pricing or Technical Support:
Contact: Miya Zheng
Email: sales@amikon.cn
WhatsApp: +86 180 2077 6792
Contact: Miya Zheng
Email: sales@amikon.cn
WhatsApp: +86 180 2077 6792
Key Features
- Seamless 3500/93 System Display Integration
Designed as the dedicated rear I/O module for the Bently Nevada 3500/93 framework, establishing a reliable hardware interface between the 3500 monitoring system spares and the local visual indication face panel. - Robust RS422 Serial Interface Communication
Equipped with a high-performance RS422 serial interface protocol, ensuring high-speed, long-distance, and noise-immune display interface connection to stream real-time machine data visualization and system event lists. - Comprehensive Machinery Status Display & Diagnostics
Supports instant local and remote visual indication of critical machinery metrics, allowing plant operators to read live alarm event lists and system diagnostics directly at the 3500/05 instrument rack. - API 670 Compliant System Reliability
Engineered to meet stringent API 670 standards for industrial rotating machinery, serving as a trusted component in critical asset protection, gas turbine protection, and emergency shutdown systems (ESD). - Versatile Power Plant & Petrochemical Applications
Extensively applied in power plant instrumentation, steam turbine diagnostics, and petrochemical equipment monitoring to maximize uptime and prevent catastrophic failures in high-value rotating assets. - Full 3500 Rack Ecosystem Compatibility
Fully compatible with the 3500 Rack Configuration Software and optimized for smooth 3500/22M TDI module integration, ensuring hassle-free hot-swapping and maintenance of Bently Nevada spare parts.
Industrial Applications
- Critical Asset Protection & Machinery Protection Systems (MPS)
Serves as the primary display interface connection within the Bently Nevada 3500 rack module. It provides real-time machine data visualization and immediate local visual indication of vibration, temperature, and thrust data across all critical plant machinery. - API 670 Compliant System Implementations
Deployed in heavy industrial environments requiring strict adherence to API 670 standards. This rear display I/O module ensures robust transmission of machine status and critical alarm event lists to high-reliability machinery protection cards. - Power Plant Instrumentation & Steam/Gas Turbine Diagnostics
Widely utilized in power plant instrumentation setups to link the 3500/93 system display with core turbomachinery. It enables continuous monitoring and remote visual indication for large-scale steam turbine diagnostics and gas turbine protection loops. - Petrochemical Equipment Monitoring & Refineries
Ideal for rugged petrochemical equipment monitor infrastructures, shielding hazardous area rotating machinery—such as large process pumps, fans, and blowers—from catastrophic failures through continuous diagnostic feeds. - Centrifugal Compressor Systems
Integrated into high-speed centrifugal compressor monitor configurations to output sub-synchronous vibration data and show system event lists, protecting complex compression trains from aerodynamic surge or mechanical damage. - Emergency Shutdown System (ESD) Integration
Acts as a reliable communication link embedded alongside emergency shutdown systems (ESD). It ensures plant operators can troubleshoot status changes on the spot via the 3500/05 instrument rack and 3500/22M TDI module integration during critical trips.
