Yokogawa AAT145-S50 S1 TC/mV Input Module – 16-Channel Isolated Input
Yokogawa AAT145-S50 S1
16-Channel Isolated Input
Thermocouple (TC) Input
Place of Origin:
JAPAN
Brand Name:
Yokogawa
Yokogawa AAT145-S50 S1
,16-Channel Isolated Input
,Thermocouple (TC) Input
AAT145-S50 S1
The Yokogawa AAT145-S50 is a TC/mV input module for industrial process measurement. Its documented specifications cover 16 isolated input channels for thermocouple and millivolt signals, supporting temperature and low-level voltage acquisition in process control systems.
Technical Specifications
| Model Reference | AAT145-S50 |
| Module Type | TC/mV Input Module |
| Input Channels | 16 isolated channels |
| Thermocouple Types | J, K, E, B, R, S, T and N |
| Millivolt Input | mV signal input; refer to the applicable hardware specification for input ranges |
| Allowable Input Voltage | ±5 V |
| Input Resistance | At least 1 MΩ, with power on or off |
| Measurement Accuracy | ±40 μV |
| Reference Junction Compensation Accuracy | ±1°C |
| Data Update Period | 1 second |
| Input-to-System Withstand Voltage | 500 V AC for 1 minute; 1,500 V AC for a single card |
| Input Channel-to-Channel Withstand Voltage | 200 V AC for 1 minute |
| Maximum Power Consumption | 350 mA at 5 V DC |
| Signal Connection | Dedicated KS1 cable |
| Weight | Approximately 0.3 kg |
Additional technical notes
| Allowable Signal Source Resistance | 1,000 Ω maximum, including wiring |
| Effect of Signal Source Resistance | ±20 μV at the specified 1,000 Ω resistance |
| Temperature Drift | ±80 μV per 10°C |
| Burnout Detection | Common channel setting; detection time 60 seconds |
Specifications above refer to the documented AAT145-S50 hardware. Confirm the complete ordering code, suffix and installed system requirements when sourcing the AAT145-S50 S1.
Application & Failure Scenarios
The module receives thermocouple and millivolt signals used in process measurement. During maintenance, it may be searched for when multiple temperature readings are lost, input values become abnormal, or a channel no longer provides reliable measurement data. An unresolved input failure can reduce process visibility and delay operating decisions, potentially affecting production continuity. Check field sensors, wiring and the associated control-system channel before replacing the module.
Documentation & Part Identification
For AAT145-S50 S1 pdf/manual/datasheet requests, contact AMIKON to discuss available documentation and confirm the exact part number. Check the full module label and installed hardware configuration before ordering a replacement.
Delivery & Warranty
Order condition and availability are confirmed with the quotation. Where applicable, the module is checked before dispatch and packed for transport. Report any damage or dead-on-arrival (DOA) issue promptly with the order reference and supporting photos. Returns require prior authorization; warranty coverage, exclusions and the claim period are confirmed in the sales terms for the supplied unit.
AMIKON Industrial Supply
Practical sourcing support for industrial automation spare parts, with attention to part identification, order details and international delivery coordination.
Share the complete model code and application details to help the team review your requirement.
Service image display area: 420 × 230 px. Recommended upload size: 840 × 460 px.
Request a Quote
Include the following information to help us process your enquiry.
| Part Number | AAT145-S50 S1 |
| Quantity | Required quantity |
| Destination | Delivery city and country |
| Required Date | Target delivery date |
| Machine/System Model | Installed control system or equipment model |
Frequently Asked Questions
1. What is the AAT145-S50 S1 used for?
It is requested for industrial process measurement applications involving the AAT145-S50 TC/mV input module. Confirm the complete suffix against the installed unit before purchase.
2. How many input channels does the AAT145-S50 provide?
The documented AAT145-S50 specification lists 16 isolated input channels.
3. Which input signals are supported?
The documented module accepts thermocouple and millivolt signals. Thermocouple types include J, K, E, B, R, S, T and N.
4. What information should I provide when ordering?
Provide the complete part number, quantity, destination, required date and machine/system model. A clear label photo can also help identify the exact variant.
5. Can AMIKON provide a datasheet or confirm replacement suitability?
Contact Miya Zheng with the full model code and system details to discuss available documentation and review the requested part. Replacement suitability should be checked against the installed configuration.
