Allen-Bradley 1756-PA75
ControlLogix AC chassis power supply for compatible 1756 control-system installations.
1756 SERIES · AC POWERProduct Overview
The 1756-PA75 provides power to the backplane of a compatible ControlLogix chassis. It is a power-supply component, not a controller or I/O module.
Technical Specifications
Electrical Ratings
Key operating valuesAdditional electrical ratings and chassis information
| Parameter | Rating / Information |
|---|---|
| Nominal input voltage | 120/240 V AC |
| 3.3 V DC output | 4.0 A maximum current capacity |
| 1.2 V DC output | 1.5 A maximum current capacity |
| 24 V DC output | 2.8 A maximum current capacity |
| Maximum inrush current | 20 A |
| Chassis references | 1756-A4, 1756-A7, 1756-A10, 1756-A13 and 1756-A17 chassis variants; confirm the exact chassis series before installation. |
Application & Failure Scenarios
ControlLogix chassis
Supplies backplane power for compatible chassis containing control-system modules.
Power interruption
A suspected supply failure or loss of chassis power may prompt a replacement search after incoming power and system status have been checked.
Production continuity
An unsuitable or failed supply can interrupt the control functions dependent on the affected chassis and delay machine recovery.
Delivery, Warranty & RFQ
Testing & packaging: Available condition and testing details are confirmed with the quotation; protective packaging is arranged for shipment. Warranty & returns: Coverage and duration follow the order confirmation. For DOA or return requests, contact AMIKON promptly with the order details, photos and fault description. Return authorization is required before shipment.
AMIKON Industrial Supply
Practical sourcing support for industrial automation parts, with order coordination for maintenance and replacement requirements.
Product Documentation
For maintenance planning and replacement identification, search for the 1756-PA75 pdf/manual/datasheet using the complete catalog number. Confirm that any technical document corresponds to the installed product and chassis.
Frequently Asked Questions
1. What is the 1756-PA75 used for?
2. What input voltage does the 1756-PA75 support?
3. Can the 1756-PA75 be replaced with a 1756-PB75?
4. What should be checked before replacing this power supply?
5. What information is needed for an AMIKON quotation?
