Product Description
IRC5 ROBOT NETWORK INTERFACE
ABB DSQC697
3HAC037084-001
A compact DeviceNet communication board used as a spare part in ABB IRC5 Single robot controllers. Verify the full product ID, RobotWare level and controller layout before replacement.
DSQC 697RobotWare 5.13+0.04 kgCanada origin
FAST PART CHECK
Need this exact board?
Send the label and controller photo to Miya Zheng for verification.
Email: sales@amikon.cn WhatsApp: +86 180 2077 679201 / DATAOfficial Product Reference
| Reference item | ABB product information |
|---|---|
| Product ID | 3HAC037084-001 |
| Catalog description | DSQC 697 DeviceNet Board |
| Controller use | Spare part for ABB IRC5 Controller, identifier 3HAC020536-014 |
| Software requirement | RobotWare 5.13 or higher |
| Replaced old product IDs | 3HAC025779-001 and 3HAC12817-1 |
| Country of origin | Canada (CA) |
| Net dimensions | 140 × 130 × 10 mm |
| Net / gross weight | 0.04 kg / 0.04 kg |
| MOQ / selling unit | 1 piece / piece |
| Customs tariff | 85176200 |
Exact-product values are kept separate from generic DeviceNet specifications so maintenance teams can verify the part without mixing data from similar boards.
02 / SIGNALIRC5 DeviceNet Architecture
RobotWare 5.13+
System configuration
System configuration
IRC5 Single
Controller platform
Controller platform
DSQC697
Network interface
Network interface
DeviceNet Bus
Industrial field network
Industrial field network
Cell Devices
I/O and compatible nodes
I/O and compatible nodes
Functional signal-path illustration for identification only. Follow ABB robot-system documentation and qualified lockout procedures for installation and wiring.
03 / WORKFLOWConfiguration & Programming Notes
Before removal
Back up the robot system, RobotWare configuration and DeviceNet settings. Record the slot, connector orientation, node configuration and status indications.
Back up the robot system, RobotWare configuration and DeviceNet settings. Record the slot, connector orientation, node configuration and status indications.
Compatibility gate
Confirm 3HAC037084-001, DSQC697, IRC5 Single hardware and RobotWare 5.13 or later. Controller options and licenses still matter.
Confirm 3HAC037084-001, DSQC697, IRC5 Single hardware and RobotWare 5.13 or later. Controller options and licenses still matter.
Installation
Isolate controller power, apply ESD protection and transfer connectors without stressing the edge contacts or mounting bracket.
Isolate controller power, apply ESD protection and transfer connectors without stressing the edge contacts or mounting bracket.
Commissioning
Restore the approved configuration, check network status and nodes, then validate robot-cell I/O under controlled conditions.
Restore the approved configuration, check network status and nodes, then validate robot-cell I/O under controlled conditions.
04 / APPLICATIONWhere the DSQC697 Fits
Robot cell I/O networking
Links an IRC5 controller with compatible DeviceNet field devices.
Links an IRC5 controller with compatible DeviceNet field devices.
Automotive automation
Maintains network communication in welding, assembly and material-handling cells.
Maintains network communication in welding, assembly and material-handling cells.
Packaging and handling
Supports installed DeviceNet architecture in palletizing, machine-tending and pick-and-place systems.
Supports installed DeviceNet architecture in palletizing, machine-tending and pick-and-place systems.
Maintenance spare
Provides an exact-part repair route for validated legacy controller layouts.
Provides an exact-part repair route for validated legacy controller layouts.
05 / LIFECYCLELifecycle & Replacement Planning
- 3HAC037084-001 / DSQC697: preferred exact-match service part after hardware and software checks.
- 3HAC025779-001: older product ID listed as replaced by 3HAC037084-001.
- 3HAC12817-1: another predecessor product ID associated with this replacement path.
- Tested exchange or repair: useful when the IRC5 platform and DeviceNet layout must remain unchanged.
- DSQC678 / 3HAC033556-001: a different IRC5 network board, not a direct DeviceNet substitute.
- Controller modernization: plan RobotWare, I/O, safety and application validation as one cell-level project.
06 / FAQField Questions, Answered
How do I identify the correct model?Match DSQC697 and the complete 3HAC037084-001 ID. Compare the label, bracket, connector and controller record.
Is it compatible with every IRC5?No. ABB links it to IRC5 Single and RobotWare 5.13 or higher; hardware, options and network design must also match.
What is its application?It provides the DeviceNet communication interface between the IRC5 controller and compatible field devices.
How should it be installed?Qualified personnel should isolate power, use ESD protection, document cable positions and recommission the network safely.
Is this board in stock?The offer is marked In Stock. Request a current inventory confirmation and product photo before payment.
What warranty is available?Typical coverage is 6–12 months according to condition and quotation; written sales terms take precedence.
How fast can it ship?Normally within 2–3 work days after payment and final part-number verification.
How is it packed?Anti-static protection, guarded connectors, cushioning and an export-ready rigid carton.
