Allen Bradley 80190-220-01-R Driver Board with 300MHz ARM Cortex-M7, 24V DC Power Supply
Allen Bradley 80190-220-01-R Driver Board with 300MHz ARM Cortex-M7, 24V DC Power Supply
300MHz ARM Cortex-M7 Driver Board
24V DC Power Supply Control Board
2A Digital Outputs Logic Interface Board
Place of Origin:
USA
Brand Name:
Allen Bradley
Model Number:
80190-220-01-R
Contact Us
Request A Quote
Product Details
Power Supply:
24V DC (±10%)
Power Consumption:
15W (max)
Input Voltage Range:
0-30V DC (digital), ±10V (analog)
Output Current:
2A (digital), 20mA (analog)
Operating Temperature:
-20°C To +60°C
Storage Temperature:
-40°C To +85°C
Humidity:
5-95% (non-condensing)
MOQ:
1 Piece
Highlight:
300MHz ARM Cortex-M7 Driver Board
,24V DC Power Supply Control Board
,2A Digital Outputs Logic Interface Board
Payment & Shipping Terms
Minimum Order Quantity
1
Price
66USD
Packaging Details
Brand new and original
Delivery Time
2-3 work days
Payment Terms
T/T
Supply Ability
in stock
RELATED PRODUCTS
Video
Allen Bradley 80190-220-01-R Driver Board with 300MHz ARM Cortex-M7, 24V DC Power Supply
Get Best Price
Video
Allen Bradley 1785-L80E/E CPU Processor Module with 48 Kilowords Memory 93 I/O Racks
Get Best Price
CONTACT US
Contact Now
Product Description
Allen Bradley 80190-220-01-R Driver Board
Technical Specifications & Performance
|
Why pull 300MHz for a driver board? Isn't that overkill?
Not when you're dealing with high-speed synchronization. The 32-bit ARM Cortex-M7 is there to eliminate logic lag. By running at 300MHz, the 80190-220-01-R handles complex interrupts and PID scaling in micro-seconds, ensuring your output response doesn't become the bottleneck in a high-speed motion or dosing loop. It's about timing precision, not just raw power.
|
How much "wiggle room" is there on the 24V DC rail?
You get a ±10% tolerance (21.6V to 26.4V). If your shop floor power is "dirty" or dips when big motors kick in, you'll want a stabilized supply. The board pulls 15W max, so it's lean, but if you drop below 21V, you risk unpredictable resets or "brown-out" behavior on the logic side.
|
|
Can I drive 2A solenoids directly off the digital outputs?
Technically, yes—the digital outs are rated for 2A. But here's the reality: if you're switching inductive loads without external flyback protection, you're asking for trouble. While the board is rugged, we always recommend an interposing relay or at least a suppression diode to keep inductive kicks from wearing down the onboard traces over time.
|
Does the ±10V analog input handle bipolar signals?
It does. The ±10V range is perfect for swing-arm sensors or any transducer that crosses a zero-point. It's a true bipolar setup. On the output side, you've got 20mA to play with, which is the industry standard for driving most proportional valves or high-impedance feedback loops without needing an extra signal booster.
|
|
Is a USA-origin part shipping from Xiamen legit?
Absolutely. This is standard global logistics. The 80190-220-01-R is an Allen-Bradley (Rockwell) design originating from the USA, but it's stocked in our Xiamen, China hub to cut down on lead times for APAC and global deployments. It's the same serialized hardware you'd get from any Rockwell distributor, just faster shipping.
|
Any special precautions for "Cold Spares" sitting in the warehouse?
The storage range is wide (-40°C to +85°C), but moisture is the real killer. Keep it in the original ESD shielding and don't let it sit in a high-humidity (over 95%) environment. If it's been sitting for years, give it a quick visual check for any "wicking" on the connector pins before you hot-swap it into a live chassis.
|
